ASGB-02-R Autonics Signal Light
Autonics ASGB-02-R Rotating Signal Light with Buzzer (Red, Ø86 mm)
The Autonics ASGB-02-R is a Ø86 mm rotating signal light with a built-in buzzer and red lens.
Designed for clear visual and audible alerts in industrial machines, automation panels, and safety systems.
Customize
Share :
The Autonics ASGB-02-R is a compact Ø86 mm rotating signal light with an integrated buzzer, designed to provide both visual and audible alerts in industrial environments. The red rotating beacon ensures high visibility, while the buzzer enhances alert effectiveness on noisy factory floors.
This model is widely used in automation systems, production lines, control panels, and safety applications to indicate machine status, faults, or warnings.
Key Features
Ø86 mm compact industrial signal light
Rotating beacon type with smooth red lens
Built-in buzzer for audible alert
High visibility even from long distance
Stud-mount design for easy installation
Multiple power supply options available (model-wise)
Rugged construction for industrial environments
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Rotating Signal Light with Buzzer |
| Model | ASGB-02-R |
| Series | ASG / ASGB |
| Lens Color | Red |
| Lens Type | Smooth |
| Light Style | Rotating with Buzzer |
| Diameter | Ø86 mm |
| Sound Level | Approx. 80 dB |
| Rotation Speed | ~130 rotations/min |
| Bulb Type | Incandescent |
| Power Supply | As per model code (DC/AC variants available) |
| Mounting Type | Stud Mount |
| Operating Environment | Industrial indoor use |
Applications
Machine status indication
Fault & alarm signaling
Industrial automation systems
Control panels & OEM machines
Production lines
Safety and warning indication
What’s in the Box?
Autonics ASGB-02-R Signal Light
Pre-wired cable
Mounting hardware
Product leaflet
FAQ
Q1. What does “ASGB” indicate in the model number?
ASGB indicates a rotating signal light with a built-in buzzer.
Q2. What color is this model?
This model comes with a red lens, commonly used for warning and fault indication.
Q3. Is the buzzer always ON with the light?
Yes. In ASGB models, the buzzer operates along with the rotating light.
Q4. Can this be used on machines and panels?
Yes. It is suitable for machines, automation panels, and industrial equipment.
Q5. Is wall mounting possible?
Yes. Optional wall-mount brackets are available separately.
